Application range
This machine is explosion-proof, over-loading, short circuit and electric leakage protection; and the over-heated,empty filter struck, oil filter clogging, wick clogging alarm and over-heat shutdown. The three protection of volume adjustment, pressure valve and safety valve prevent over-pressure operation. The oil and gas separator element adopts import thin glass fiber and controls the content of air compressor under 3 ppm
Characteristics
This machine can be operated near the dig working face of the underground mining, and it can be moved forward,so it can be maintain high air pressure, the efficiency of this product can be raised 30% to 100%, the power consuming will be 30% less, and save great amount of pipes.
Technical parameters
|
Model |
MLGF3.6/7-22G |
MLGF6/7-37G |
LGF7.6/7-45G |
MLG10/8-55G |
|
Gas displacement (M3/min) |
3.6 |
6 |
7.6 |
10 |
|
Discharge pressure (MPa) |
0.7 |
0.7 |
0.7 |
0.8 |
|
Applied voltage (V) |
380/660 |
380/660(660/1140) |
380/660(660/1140) |
380/660(660/1140) |
|
Main engine power (kw) |
22 |
37 |
45 |
55 |
|
Explosive-proof mark |
ExdI |
ExdI |
ExdI |
ExdI |
|
Weight (kg) |
1160 |
1600 |
1700 |
2250 |
|
Length×width×height (mm) |
2300×960×1330 |
2730×1100×1400 |
2940×1200×1480 |
2940×1200×1480 |
|
Track gauge (mm) |
600/762/900 |
600/762/900 |
600/762/900 |
600/762/900 |
|
|
||||
|
Model |
MLGF13/7-75G |
MLGF16/8-90G |
LGF21/8-132G |
MLG25/8-160G |
|
Gas displacement (M3/min) |
13 |
16 |
21 |
25 |
|
Discharge pressure (MPa) |
0.7 |
0.8 |
0.8 |
0.8 |
|
Applied voltage (V) |
380/660(660/1140) |
380/660(660/1140) |
380/660(660/1140) |
380/660(660/1140) |
|
Main engine power (kw) |
ExdibI |
ExdibI |
ExdibI |
ExdibI |
|
Explosive-proof mark |
ExdI |
ExdI |
ExdI |
ExdI |
|
Weight (kg) |
2600 |
2648 |
3725 |
3760 |
|
Length×width×height (mm) |
3240×1210×1550 |
3240×1210×1550 |
3560×1360×1695 |
3740×1360×1745 |
|
Track gauge (mm) |
600/762/900 |
600/762/900 |
600/762/900 |
600/762/900 |
|
|
||||
|
Model |
MLGF30/8-185G |
MLGF35/8-200G |
MLGF42/8-250G |
MLG 42/8-250G |
|
Gas displacement (M3/min) |
30 |
35 |
42 |
42 |
|
Discharge pressure (MPa) |
0.8 |
0.8 |
0.8 |
0.8 |
|
Applied voltage (V) |
660/1140 |
660/1140 |
660/1140 |
660/1140 |
|
Main engine power (kw) |
185 |
200 |
250 |
250 |
|
Explosive-proof mark |
ExdI |
ExdI |
ExdI |
ExdI |
|
Weight (kg) |
4235 |
4255 |
5860 |
5860 |
|
Length×width×height (mm) |
3850×1430×1850 |
3850×1430×1850 |
4450×1600×2000 |
4300×1600×2000 |
|
Track gauge (mm) |
600/762/900 |
600/762/900 |
600/762/900 |
600/762/900 |
Note: The voltage and track gauge are determined by the contract agreement between the parties.
