Characteristics
The characteristics of this machine: energy saving; environment protection; easy operation and advanced design concept. It is highly reliable, the main engine warrant for 3 years, the whole machine warrant for 1year; energy saving, the latest design of screw assembly is the most efficient in the field.; low voice, quieter working environment, environment protecting, no leaking design, low energy consuming, easy maintaining, compact structure, nit outlook, long period between maintain, low cost.
Technical parameters
|
Model |
LGYT-0.5/8 |
LGYT-0.46/10 |
LGYT-0.4/13 |
|
Discharge pressure (MPa) |
0.8 |
1.0 |
1.3 |
|
Displacemint (m3/min) |
0.5 |
0.46 |
0.4 |
|
Power (kW) |
4 |
4 |
4 |
|
Noise dB(A) |
76 |
76 |
76 |
|
Dimension (mm) |
1200x550x1100 |
1200x550x1100 |
1200x550x1100 |
|
|
|||
|
Model |
LGYT-0.8/8 |
LGYT-0.7/10 |
LGYT-0.6/13 |
|
Discharge pressure (MPa) |
0.8 |
1.0 |
1.3 |
|
Displacemint (m3/min) |
0.8 |
0.7 |
0.6 |
|
Power (kW) |
5.5 |
5.5 |
5.5 |
|
Noise dB(A) |
77 |
77 |
77 |
|
Dimension (mm) |
1200x550x1100 |
1200x550x1100 |
1200x550x1100 |
|
|
|||
|
Model |
LGYT-1.2/8 |
LGYT-1.0/10 |
LGYT-0.8/13 |
|
Discharge pressure (MPa) |
0.8 |
1.0 |
1.3 |
|
Displacemint (m3/min) |
1.2 |
1.0 |
0.8 |
|
Power (kW) |
7.5 |
7.5 |
7.5 |
|
Noise dB(A) |
79 |
79 |
79 |
|
Dimension (mm) |
1312x600x1140 |
1312x600x1140 |
1312x600x1140 |
|
|
|||
|
Model |
LGYT-1.7/8 |
LGYT-1.5/10 |
LGYT-1.2/13 |
|
Discharge pressure (MPa) |
0.8 |
1.0 |
1.3 |
|
Displacemint (m3/min) |
1.7 |
1.5 |
1.2 |
|
Power (kW) |
11 |
11 |
11 |
|
Noise dB(A) |
79 |
79 |
79 |
|
Dimension (mm) |
1420x640x1140 |
1420x640x1140 |
1420x640x1140 |
